Fences

Free Revit Fence Families and Boundary Enclosures

Our Revit fence families collection covers site boundaries in RFA and RVT format: timber picket and slat fences, wrought iron railings, mesh and chain-link enclosures, precast panels and decorative garden screens. Boundaries define how a site reads long before the building does, so it is worth modeling them properly rather than leaving the plot edge as a line on the survey.

What you get in this category

• Timber fences (.rfa) — picket, slat and solid board panels for residential boundaries.
• Metal fences and railings (.rfa) — wrought iron, tubular and decorative metalwork for perimeters and gardens.
• Mesh and security enclosures (.rfa) — chain-link and welded mesh for industrial sites, courts and utility areas.
• Fence assemblies (.rvt) — complete boundary runs with posts and gates you can adapt to your plot.
• Free and Premium downloads — most files are free with a registered account; a subscription unlocks the full library.

Fences on sloping ground

The recurring problem with boundary fences is topography. A fence family placed as a single component will sit level and float or bury itself as the ground falls away, which is why long runs are usually better handled as Revit railing system types: railings follow a sketched path and can be set to step or slope with the terrain. Loadable fence panels are the right choice for short runs, decorative screens and anywhere you need specific geometry that a railing type cannot produce. Whichever you use, check the post spacing against the panel width so the run does not end with an awkward offcut, and confirm the family’s height matches your local boundary regulations, since front and rear boundaries often have different limits.

Related outdoor categories

Completing the site? Browse our outdoor furniture, garden decorations and lattice frames, or the full parks and gardens category.

Frequently asked questions

Are these Revit fence families free?
Yes. Most files are free to download with a registered account. A Premium subscription removes limits and unlocks the full library.

How do I run a fence along sloping ground?
For long runs on uneven terrain, a Revit railing type following a sketched path handles slope better than repeated loadable panels. Use loadable families for short runs and decorative sections.

Can I change the height of a fence family?
Parametric families expose height and post spacing as type parameters. Fixed-geometry panels need editing in the Family Editor.
