Parametric Loop hanger
A loop hanger is a versatile and widely used support device in piping systems. It is designed to suspend horizontal pipes securely from ceilings, beams, or other structural elements. The hanger consists of a circular metal band or strap that wraps entirely around the pipe, with a bolt or fastener at the top for securing the loop and connecting it to a support rod or bracket.
- Format RFA
- File Size 528.00 KB
- Company
