Rainwater drainage system model combines prefabricated canal channels with integrated street lighting for modern urban stormwater control. The layout shows plan and elevation coordination for streetscapes.
Modeled as a detailed BIM object, it supports placement of modular rainwater drainage runs, geometric flow paths, lighting poles, trees, and pedestrian-friendly edges for residential or commercial infrastructure.
This rainwater drainage asset helps document sustainable streets, plazas, and public works where water management and illumination must be coordinated efficiently within the same model.
- Format RVT
- File Size 824.58 KB
- Version
- Company
