This water filtration room BIM model presents a compact purification layout with carbon tanks, zeolite media, and a softener arranged for clear equipment coordination and onsite planning.
Color-coded piping in blue and green highlights flow paths, while the utilitarian 3D room layout supports spatial review, maintenance access, and daily production planning for up to 300 purified drinking water jugs.
Use this water filtration room for commercial, hospitality, or service facilities requiring reliable potable water capacity over a 12-hour operating window and efficient BIM documentation.
- Format RVT
- File Size 17.95 MB
- Version
- Company
