Wooden sash window with 2 leaves and sill

This wooden sash window Revit family provides a clean 2D constructive detail for classic two-leaf window assemblies with a defined sill and balanced proportions for documentation.

The drawing focuses on sash and sill geometry, showing wood frame relationships, leaf separation, and technical linework suitable for residential construction documents or renovation sets.

Use this wooden sash window detail in living rooms, bedrooms, and heritage-style projects where traditional material expression and clear drafting standards matter for approvals and coordination.
