Modular Kitchen Layout, Parametric

Revit Family of a modular kitchen component for residential units and small hospitality suites, combining base/upper cabinets, countertop, sink, cooktop, hood, refrigerator, and dining set. Includes parametric controls for run length, cabinet widths, depths, counter and wall-unit heights, backsplash and toe-kick, plus material parameters.

Comes with predefined types for linear, L-shaped, and galley configurations, modeled at LOD 300 with plumbing and electrical connectors for accurate coordination and scheduling.
