T-bar ceiling system detailed grid

T-bar ceiling system

This T-bar ceiling system supports suspended gypsum board ceilings with a clean metal grid, rods, and clips. It is suited for coordinated ceiling layouts in commercial, retail, and residential interiors.

The model shows installation layout and elevation views for clear documentation. Use it to study hanger spacing, support connections, gypsum surface alignment, and lighting coordination within a T-bar ceiling system.

  • Format RVT
  • File Size 16.75 MB
  • Version
  • Company
DOWNLOAD RVT
